Brand: SUNWORTH
Product Origin: China
Power Range: 50W-85W
Solar Cell: Monocrystalline
Certificate: CE/TUV/CB/IEC/RoHS
Warranty: 25 years
85W Monocrystalline Solar Panel
Description
Descriptions:
50W~85W Sunworth high efficiency mono solar panel not only have a nice price but also the quality stands the test.
Advantages of Sunwoth 50~85W High Efficiency Mono Solar Panels:
- Professional crystalline silicon photovoltaic module manufacturer
- Fully automated production line with leading photovoltaic technology
- Strong Low-light performance
- Adopt strict international standard quality management system ISO 9001 and ISO 14001
- Twice EL test to ensure the reliability of the solar panels
| Electrical Parameters | ||||
| Model No. | SW050M-36 | SW060M-36 | SW075M-36 | SW085M-36 |
| Max Power | 50W | 60W | 75W | 85W |
| Max Voltage | 18.50V | 19.55V | 18.50V | 19.28V |
| Max Current | 2.71A | 3.07A | 4.06A | 4.41A |
| Open-circuit Voltage | 23.27V | 24.11V | 23.22V | 23.54V |
| Short-circuit Current | 2.98A | 3.25A | 4.30A | 4.70A |
| Module Efficiency | 14.29% | 17.15% | 14.74% | 16.71% |
| Operating Temperature | -40℃~+85℃ | |||
| Max System Voltage | 300Vdc | |||
| Max Series Fuse Rating | 10A | |||
| Power Tolerance | ±3% | |||
| *STC condition：1000 W/m² | 1.5AM and 25℃ cell temperature | |||
| Temperature parameters | ||||
| NMOT | 46℃±2℃ | |||
| Temperature Co-efficient of Pmax | -0.398%/℃ | |||
| Temperature Co-efficient of Voc | -0.340%/℃ | |||
| Temperature Co-efficient of Isc | 0.0576%/℃ | |||
| Mechanical Parameters | ||||
| Cell size | 156.75*52.25mm | 156.75*52.25mm | 156.75*78.38mm | 156.75*78.38mm |
| Cell amounts | 36(4*9) | 36(4*9) | 36(4*9) | 36(4*9) |
| Weight | 2.4kg | 2.4kg | 5.5kg | 5.5kg |
| Module Dimensions | 660*530*25mm | 660*530*25mm | 665*765*30mm | 665*765*30mm |
| Front Cover | 3.2mm tempered glass | |||
| Frame Material | Anodized aluminium alloy | |||
| Junction Box | IP65 rated | |||
Q1:Do you provide after-sales service?
A:More than 50 professional operation and maintenance engineers to solve problems and
provide service for you at any time.
Q2:What solar solutions can you provide?
A:Residential/Home solar system, Rooftop solar power station, Large-scale ground-mounted
solar power station,Agriculture-complementary Solar Power Station.
Q3:What is the lead time?
A:It will take about 5-20 days for production depending on the quantity.
Q4:How long is the warranty of your products?
A:5-year Warranty for Materials and Processing 25-year Warranty for Extra Linear Power Output.
Q5:Can I have sample before formal order?
A:Of course.
Q6:OEM is available?
A:Acceptable OEM Service
