Descriptions:
An off-grid PV energy storage system is the first choice for customers in remote areas without electricity supply. Different customers can choose different system power according to the daily power consumption.
Sunworth is a reliable solar system factory that can provide you with a suitable 6-10kw off-grid home solar power system. Contact us to lower your cost of a 10kw solar system with battery storage!
Advantage of 10kw Off Grid Solar System With Battery Storage
- Rated Power: 6KW-10KW, pure sine wave output.
- Built-in MPPT 60A/70A/80A MPPT solar controller.
- MPPT PV controller tracking the maximum power point to achieve the maximum power output.
- Simple installation. Just need to properly install the PV module and connect them to the integrated power cabinet. The system then can be used.
- 12 years of manufacturing experience in PV products.
Technical Data |
Model No. |
SW-SPS6KW-Li |
SW-SPS8KW-Li |
SW-SPS10KW-Li |
Solar Panel Power |
12x320Wp |
16x320Wp |
20x320Wp |
Lithium Battery |
9.6KWh |
14.4KWh |
17.28KWh |
Rated Power |
6KVA/6KW |
8KVA/8KW |
10KVA/10KW |
Surge Rating |
18KVA |
24KVA |
30KVA |
Max. Solar Charge |
MPPT 80A |
MPPT 120A |
MPPT 120A |
Max.AC Charge |
60A |
70A |
80A |
Input Voltage |
AC 220V/230V 50Hz |
Output Voltage |
AC 220V/230V 50Hz , 1x Flash Charge USB ,2x5V USB(2.1A) |
Protection |
Surge, Reverse polarity, Overload, Short circuit ,etc. |
Operating Temperature |
Discharge: -20℃ ~50℃,Charge: 0℃~50℃ |
IP Rating |
IP22 |
Inverter Size |
650*380*225mm |
Battery Cabinet Ref. |
60×60×60 cm |
60×60×80 cm |
60×50×100 cm |
Weight(Ref.) |
520Kgs |
680Kgs |
930Kgs |
Q1: What devices can Squirrel15 power?
A: Squirrel15 can charge the DC device under 60W for DC port.
Q2: Do you make customized products?
A: We warmly welcome OEM/ODM orders.
Q3: What is the minimum number of order for this product?
A: Normally MOQ 100 pcs.
Q4: Can I get a sample before order?
A: After price confirmation, you can require for samples to check our product’s quality.
Q5: What is your term of delivery?
A: We accept FOB Shenzhen or CIF. It’s up to you.
Reviews
There are no reviews yet.
