SHS with Lead-acid Battery DC Series 60W~160W

Home|Solar Power Storage System|Lead-acid Battery Series|SHS with Lead-acid Battery DC Series 60W~160W

SHS with Lead-acid Battery DC Series 60W~160W


Product Origin: China

Product Name: Solar Home Kit

Power Source: Solar Panel/AC Adaptor

Battery Type: Lead-acid

Controller Type: MPPT

Output: DC,USB

Service: ODM/OEM

Certificate: CE

Warranty: 2 year



It’s a small and portable solar home system kit. Can be used for power home DC LED bulbs, fan, TV, and charge mobile phones. Very easy installation, install the solar module on roof or yard, with best orientation and angle to get sunlight and connect the solar module with power box. Ensure full charging to the batteries every time, and at least keep 50% of electricity to ensure the service life of the battery.


Advantage of Sunworth 60~160W Off-grid Solar Home System with Lead-acid Batteries DC Series.

Solving daily emergency electricity in family and remote areas.

Passed TUV, IEC, CE, ETL and other tests.

Integrated quality control and inspection procedures during production, ensuring high product quality.

Easy and fast installation, save time and space.

Customized solutions can be provided.


Technical Data
Solar Panel Power 60Wp 80Wp 100Wp 160Wp
Lead-acid Battery 12V38Ah 12V55Ah 12V65Ah 12V100Ah
Controller 10A 10A 10A 10A
LED Bulb 5W*6 PCS 5W*6 PCS 5W*6 PCS 5W*6 PCS
Max. Charge Current 10A 10A 10A 10A
Inverter(optional) 300W 300W 500W 500W
Output Voltage DC12, DC5V
DC Outlet Socket DC12V Socket *8Pcs,1x Flash Charge USB ,2x5V USB(2.1A)
Protection Surge, Reverse polarity, Overload, Short circuit ,etc.
Operating Temp Discharge: -20℃ ~50℃,Charge: 0℃~50℃
IP Rating IP22
Power Box (L*W*H) 28x21x23 CM 31x21x27 CM 43*21*25 CM 41*22*29 CM
Weight 22Kgs 29Kgs 34Kgs 46Kgs


Q1: What devices can the system power?
A: The system can charge the DC device under 120W for DC port.

Q2: Do you make customized products?
A: We warmly welcome OEM/ODM orders.

Q3: What is the minimum number of order for this product?
A: Normally MOQ 100 pcs.

Q4: Can I get a sample before order?
A: After price confirmation, you can require for samples to check our product’s quality.

Q5: What is your term of delivery?
A: We accept FOB Shenzhen or CIF. It’s up to you.
