Description
Descriptions:
- Smart inverter built-in MPPT tracker
- Enhanced AC/solar charger to 1C
- Programmable supply priority for PV, battery or grid
- User-adjustable battery charging current
- Battery independent design
- Monitoring APP (Andriod and iOS) for real-time status display and parameter control
- Compatible to utility and generator
- Lithium Iron Phosphate (LFP) cell
| Model No. | SESS-20KWh |
| Nominal output power | 11000W |
| Solar power input | 16x500Wp |
| Battery capacity | 20.48KWh |
| Battery type | LFP(LiFePO4) |
| Hybrid Inverter specification | |
| Rated power | 11000VA/11000W |
| Surge power | 22000VA |
| Waveform | Pure sine wave |
| AC Voltage Regulation (Batt.Mode) | 220VAC~240VAC |
| Inverter Efficiency(Peak) | 93% |
| Transfer Time | 15ms(For personal computers) / 20ms（For home appliances) |
| AC input voltage | 230Vac |
| Frequency Range | 50Hz / 60Hz (Auto sensing) |
| Maximum PV Array Open Circuit Voltage | 500Vdc |
| PV Array MPPT Voltage Range | 90-450Vdc |
| Maximum PV Array Power | 10000Wp(5000Wp x2) |
| Maximum Solar Charge Current | 150A |
| Maximum AC Charge Current | 150A |
| Dimension(mm) | 158x504x531 |
| Net Weight (KGS) | 20 |
| Battery Module | |
| Nomal voltage | 51.2V |
| Capacity | 100Ah |
| Full charge voltage | 58.4V |
| Full discharge voltage | 43.2V |
| Charge current | 20A(0.2C) |
| Max. charging current | 100A |
| Max. discharging current | 100A |
| Protection | BMS,Breaker |
| Dimension(mm) | 482*550*178 |
| Net Weight (KGS) | 45 |
| Number of modules | x 4 |
| Other | |
| Relative humidity | 5% to 95% |
| Operating temperature | –10℃ to +50℃ |
| Storage temperature | –15℃ to +60℃ |
Q1: What devices can the system power?
A: The system can charge the DC device under 120W for DC port and AC device under inverter power
(500W, 800W or 1000W, depends on the model No.), please refer to the specifications for details.
Q2: Do you make customized products?
A: We warmly welcome OEM/ODM orders.
Q3: What is the minimum number of order for this product?
A: Normally MOQ 100 pcs.
Q4: Can I get a sample before order?
A: After price confirmation, you can require for samples to check our product’s quality.
