Description
Descriptions:
- High-efficiency solar cells to maintain solar panel efficiency at 20.04%.
- Lower LID attenuation.
- Excellent performance under weak light conditions.
- Excellent temperature coefficient characteristics.
- Premium materials ensure reliability.
- 100% EL testing ensures top quality.
- Extreme environment durability certified by TUV.
- Custom specifications available.
| Electrical Characteristics | |||
| Model No. | SW350M | SW360M | SW365M |
| Maximum power (Pmax) | 350W | 360W | 365W |
| Max-power voltage (Vmp) | 27.12V | 27.26V | 27.36V |
| Max-power current (Imp) | 12.91A | 13.21A | 13.34A |
| Open-circuit voltage (Voc) | 32.0V | 32.17V | 32.28V |
| Short-circuit current (Isc) | 13.68A | 13.99A | 14.13A |
| Module efficiency | 20.04% | 20.06% | 20.90% |
| Operating temperature | -40℃~+85℃ | ||
| Maximum system voltage | 1500Vdc | ||
| Maximum series fuse rating | 30A | ||
| Power tolerance | ±3% | ||
| *STC condition：1000 W/m²,1.5AM and 25℃ cell temperature. | |||
| Temperature Characteristics | |||
| NOCT | 46℃±2℃ | ||
| Temperature co-efficient of Pmax | -0.36%/℃ | ||
| Temperature co-efficient of Voc | -0.28%/℃ | ||
| Temperature co-efficient of Isc | 0.048%/℃ | ||
| Mechanical Characteristics | |||
| Mono power | 350W/360W/365W | ||
| Cell type | Mono 182*91mm | ||
| Cell arrangement | 96(6*16) | ||
| Dimensions | 1540*1134*35mm | ||
| Weight | 18.2kg | ||
| Front cover | 3.2mm tempered glass | ||
| Frame material | Anodized aluminium alloy | ||
| Junction box | IP67 rated | ||
| Output cables | 4mm²,length：（+）300mm/（-）300mm | ||
| Packing Ref. | |||
| Container | 40’HC | ||
| Pieces/pallet | 31 | ||
| Pieces/container | 868 | ||
Q1:Do you provide after-sales service?
A:More than 50 professional operation and maintenance engineers to solve problems and provide service for you at any time.
Q2:What solar solutions can you provide?
A:Residential/Home solar system, Rooftop solar power station, Large-scale ground-mounted solar power station,Agriculture-complementary Solar Power Station.
Q3:What is the lead time?
A:It will take about 5-20 days for production depending on the quantity.
Q4:How long is the warranty of your products?
A:5-year Warranty for Materials and Processing 25-year Warranty for Extra Linear Power Output.
Q5:Can I have sample before formal order?
A:Of course.
Q6:OEM is available?
A:Acceptable OEM Service
